CANTER LEVEL SIDE SEALING MACHINES WITH PATENTED FILM FEED SYSTEM





  • Excitement never ends. Star will win you over at first glance. More charm, less consumption. The thrill of an evolution that respects tradition. Progress and emotion, versatility and speed in the first canterlevel side sealing wrapper that works with center folded and flat film.
    Patented and exclusive system.


    GENERAL FEATURES
    The side sealing canter level machine that join the advantages of the side sealing machine like the versatility and flexibility to the advantages of the flowpack machine: speed and tight bag. Versatility: first side sealing machine that can work with center folded and flat film in the same machine with the same film dispenser unit. Patented system . Can work with neutral or pre printed film and can work with all films like: Polyolefin, Polypropylene, Bopp, Pe; Barrier BDF film. Flexibility: fast change of film and fast change of products. Products’ width up to 600 mm; unlimited length. Film dispenser unit up to 750 mm for both Flat and Center folded film. Output/ speed: available in 2 versions : intermittent and box motion, out put up to 150 pcs/min. Tight Bag: first side sealing machine that works with the same film width as a flowpack machine with a final result of a very tight bag. Film saving: no more than 1 cm of waste canter level structure that allows an easy cleaning and accessibility of the machine, perfect in the Food Industry as it can work with BDF film also in Modified Atmosphere MAP. Stainless steel version available can be combined with a canter level shrink tunnel with opening chamber.

    SPECIFIC FEATURES
    Patented system: first machine in the world able to work with center folder and flat film in the same machine. Available in 2 versions intermittent and box motion : output up to 150 pcs/min film: poliolefine, polypropylene, BOPP, PE, Barrier Film. Film saving: no more than 1 cm waste film tight bag as in a flowpack machine.
    And optional: patented saving energy system with siemens-50% of machine consumption saved. Canterlever shrink tunnel with movable and opening shrink tunnel. Canterlever additional in feed belt. Available also in stainless steel version.









TUNNEL FEATURES INCLUDE:

    • Fully re-circulating Air Chamber
    • Live Roller Rod Conveyor
    • Solid State digital Temperature Control
    • AC Variable Speed Drive
    • Independent Heater on/off switch
    • Automatic Cool down with Shut off
    • Tunnel can be moved by handles horizontally to be centered with products



BENEFITS:

    • Touching belt
    • Touch screen
    • 5 Inverters (Every motor is supplied with one Inverter)
    • Motors: ABB
    • Electronics: SIEMENS
    • The sealing bar is vertical instead of having the ‘scissors’ shape’
    • The operator is allowed to control, to increase or decrease the speed of the machine.

Power : 220V - 42 amps (50A service)

Needs house air









      COMPONENTS:

Motors:
Reducers:
Bearings and Supports :
Pneumatics’ components :
PLC :
Electro - mechanic’s components :
Inverter  :
Rele’ :

ABB
MOTOVARIO
SKF
KUHKNE
SIEMENS
MITSHUBISHI
MITSHUBISHI
OMRON
